具有较高的硬度和韧性
优异的软磁性能，磁导率较高
具有良好的热稳定性
能够存储更多的磁能，提高磁存储器件的性能
工作温度：-40℃～+125℃(包含线圈发热)
适用于高速数据传输和高频电子设备
外观尺寸Outline dimension
外观参数Exterior size / 单位：mm
电气特性Electrical / 单位：mm
型号/NO
L/uH
DCR（Ω）
Max
Isat
(Amperes)
Irms
(Amperes)
PDF
注释Notes
选型避坑要点Key Selection Notes
Prioritize saturation current for selection; reserve more than 30% current margin in practical use to avoid inductance saturation failure.
2、温升电流同样预留 20% 以上余量，防止长期工作过热.
Reserve over 20% margin for temperaturerise current to prevent overheating under longterm operation.
3、高频场景需兼顾直流电阻 DCR，降低发热与损耗，功率预留合理余量.
Consider DC resistance (DCR) for highfrequency applications to reduce heat generation and power loss, with reasonable power margin reserved.
4、实际工作温度高于 25℃时，电流进一步降额，放大余量.
Further derate operating current and increase margin when actual working temperature exceeds 25°C.
